调用方式

以下为 StartMix（开始混流）接口的请求结构为例：

https://rtc-api.zego.im/?Action=StartMix
&AppId=1234567890
&SignatureNonce=15215528852396
&Timestamp=1234567890
&Signature=7a2c0f11145fb760d607a07b54825013
&SignatureVersion=2.0
&IsTest=false

其中：

• https：指定了请求通信协议。
• rtc-api.zego.im：指定了 ZEGO 服务端的接入地址。
• Action=StartMix：指定了要调用的 API。
• 其它参数：即公共请求参数，是每个接口都需要使用到的请求参数，包含 AppId、SignatureNonce、Signature 等，具体请参考 公共请求参数。

此外，ZEGO 提供多种编程语言的示例代码，开发者可根据实际情况进行参考。以下是 StartMix接口的 Node.js 代码：

const crypto = require('crypto');
const request = require('request');

//请将 AppId 修改为你的 appId，appId 为 number
var appId = ;
//请将 serverSecret 修改为你的 serverSecret，serverSecret 为 string
var serverSecret = "";

//Signature=md5(AppId + SignatureNonce + ServerSecret + Timestamp)
function GenerateSignature(appId, signatureNonce, serverSecret, timeStamp) {
    const hash = crypto.createHash('md5'); //规定使用哈希算法中的 MD5 算法
    var str = appId + signatureNonce + serverSecret + timeStamp;
    hash.update(str);
    //hash.digest('hex')表示输出的格式为 16 进制
    return hash.digest('hex');
}

var signatureNonce = crypto.randomBytes(8).toString('hex');
var timeStamp = Math.round(Date.now() / 1000);
var sig = GenerateSignature(appId, signatureNonce, serverSecret, timeStamp);

//以下示例 将 streamId 为 "stream1" 的音视频流 与 streamId 为 "stream2" 的音视频流进行混流，混出 streamId 为 "stream3" 的音视频流
var url = `https://rtc-api.zego.im/?Action=StartMix&AppId=${appId}&SignatureNonce=${signatureNonce}&Timestamp=${timeStamp}&Signature=${sig}&SignatureVersion=2.0&IsTest=false`;
var body = {
    'TaskId': '123',
    'Sequence': 123,
    'UserId': '123',
    'MixInput': [
    {
        'StreamId': 'stream1',
        'RectInfo': {
            "Top": 70,
            "Bottom": 160,
            "Left": 100,
            "Right": 260
        },
    },
    {
        'StreamId': 'stream2',
        'RectInfo': {
            "Top": 200,
            "Bottom": 290,
            "Left": 100,
            "Right": 260
        },
    }
    ],
    'MixOutput': [{
        'StreamId': 'stream3',
        'Width': 360,
        'Height': 360,
        'VideoBitrate': 12000,
        'Fps': 15
    }]
}

request({
    url: url,
    method: 'POST',
    json: true,
    headers: {
        'content-type': 'application/json'
    },
    body: body
}, function (error, response, body) {
    console.log(error)
    console.log(response.statusCode)
    if (!error && response.statusCode === 200) {
        console.log(body.Data)
    }
})

import (
   "crypto/md5"
   "crypto/rand"
   "encoding/hex"
   "fmt"
   "log"
   "time"
)
// Signature=md5(AppId + SignatureNonce + ServerSecret + Timestamp)
func GenerateSignature(appId uint32, signatureNonce string, serverSecret string, timestamp int64) (Signature string){
   data := fmt.Sprintf("%d%s%s%d", appId, signatureNonce, serverSecret, timestamp)
   h := md5.New()
   h.Write([]byte(data))
   return hex.EncodeToString(h.Sum(nil))
}
func main() {
   /*生成16进制随机字符串(16位)*/
   nonceByte := make([]byte, 8)
   rand.Read(nonceByte)
   signatureNonce := hex.EncodeToString(nonceByte)
   log.Printf(signatureNonce)
   appId := 12345       //使用你的appId和serverSecret
   serverSecret := "9193cc662a4c0ec135ec71fb57194b38"
   timestamp := time.Now().Unix()
   /* appId:12345
      signatureNonce:4fd24687296dd9f3
      serverSecret:9193cc662a4c0ec135ec71fb57194b38
      timestamp:1615186943      2021/03/08 15:02:23
      signature:43e5cfcca828314675f91b001390566a
    */
   log.Printf("signature:%v", GenerateSignature(uint32(appId), signatureNonce, serverSecret, timestamp))
}

# -*- coding: UTF-8 -*-
import secrets
import string
import hashlib
import time
#Signature=md5(AppId + SignatureNonce + ServerSecret + Timestamp)
def GenerateSignature(appId, signatureNonce, serverSecret, timestamp):
    str1 = str(appId) + signatureNonce + serverSecret + str(timestamp)
    hash = hashlib.md5()
    hash.update(str1.encode("utf8"))
    signature = hash.hexdigest()
    return signature

def main():
    #生成16进制随机字符串(16位)
    signatureNonce = secrets.token_hex(8)

    #使用你的appId和serverSecret
    appId = 12345
    serverSecret = "9193cc662a4c0ec135ec71fb57194b38"
    #获得10位unix时间戳
    timestamp = int(time.time())
    print(GenerateSignature(appId,signatureNonce,serverSecret,timestamp))

if __name__ == '__main__':
    main()

import java.security.MessageDigest;
import java.security.SecureRandom;
public class Md5{
    /**
     * 字节数组转16进制
     * @param bytes 需要转换的byte数组
     * @return  转换后的Hex字符串
     */
    public static String bytesToHex(byte[] bytes) {
        StringBuffer md5str = new StringBuffer();
        //把数组每一字节换成16进制连成md5字符串
        int digital;
        for (int i = 0; i < bytes.length; i++) {
            digital = bytes[i];
            if (digital < 0) {
                digital += 256;
            }
            if (digital < 16) {
                md5str.append("0");
            }
            md5str.append(Integer.toHexString(digital));
        }
        return md5str.toString();
    }
    // Signature=md5(AppId + SignatureNonce + ServerSecret + Timestamp)
    public static String GenerateSignature(long appId, String signatureNonce, String serverSecret, long timestamp){
        String str = String.valueOf(appId) + signatureNonce + serverSecret + String.valueOf(timestamp);
        String signature = "";
        try{
            //创建一个提供信息摘要算法的对象，初始化为md5算法对象
            MessageDigest md = MessageDigest.getInstance("MD5");
            //计算后获得字节数组
            byte[] bytes = md.digest(str.getBytes("utf-8"));
            //把数组每一字节换成16进制连成md5字符串
            signature = bytesToHex(bytes);
        }catch (Exception e) {
            e.printStackTrace();
        }
        return signature;
    }


    public static void main(String[] args){
        //生成16进制随机字符串(16位)
        byte[] bytes = new byte[8];

        //使用SecureRandom获取高强度安全随机数生成器
        SecureRandom sr = new SecureRandom();

        sr.nextBytes(bytes);
        String signatureNonce = bytesToHex(bytes);
        long appId = 12345L;       //使用你的appId和serverSecret，数字后要添加大写L或小写l表示long类型
        String serverSecret = "9193cc662a4c0ec135ec71fb57194b38";
        long timestamp = System.currentTimeMillis() / 1000L;
        System.out.println(GenerateSignature(appId,signatureNonce,serverSecret,timestamp));
    }
}

<?php
function GenerateSignature($appId, $signatureNonce, $serverSecret, $timestamp)
{
    $str = $appId.$signatureNonce.$serverSecret.$timestamp;
    $signature = md5($str);
    return $signature;
}

//生成16进制随机字符串(16位)
$signatureNonce = bin2hex(random_bytes(8));
//使用你的appId和serverSecret
$appId = 12345;
$serverSecret = "9193cc662a4c0ec135ec71fb57194b38";
$timestamp = time();
$signature = GenerateSignature($appId, $signatureNonce, $serverSecret, $timestamp);
echo $signature;
?>

const crypto = require('crypto');
//Signature=md5(AppId + SignatureNonce + ServerSecret + Timestamp)
function GenerateUASignature(appId, signatureNonce, serverSecret, timeStamp){
    const hash = crypto.createHash('md5'); //规定使用哈希算法中的MD5算法
    var str = appId + signatureNonce + serverSecret + timeStamp;
    hash.update(str);
    //hash.digest('hex')表示输出的格式为16进制
    return hash.digest('hex');
}

var signatureNonce = crypto.randomBytes(8).toString('hex');
//使用你的appId和serverSecret
var appId = 12345;
var serverSecret = "9193cc662a4c0ec135ec71fb57194b38";
var timeStamp = Math.round(Date.now()/1000);
console.log(GenerateUASignature(appId, signatureNonce, serverSecret, timeStamp));
